Typical maximum* read range:
- ProxCard II card up to 3.0″ (7.6 cm)
- ISOProx II card up to 2.5″ (6.35 cm)
- DuoProx II card up to 2.5″ (6.35 cm)
- Smart ISOProx II up to 2.5″ (6.35 cm)
- Smart DuoProx II up to 2.5″ (6.35 cm)
- HID Proximity & MIFARE® Card up to 2.5″ (6.35 cm)
- ProxCard Plus card up to 1.0″ (2.5 cm)
- ProxKey II Keyfob up to 1.5″ (3.8 cm)
- Microprox Tag up to 2.0 ” (5.1 cm)
*Depending on local installation conditions.
Dimensions
5.25″ x 2.75″ x 1.625″ (13.33 x 6.98 x 4.1 cm)
Power Supply/ Current Requirements
10 – 15 VDC, reverse voltage protected
Linear supply recommended, 150 mA @ 12 VDC
Relay Outputs
Strike Relay – Form C, switches up to 1A @ 30 VDC
Aux Relay – Form C, switches up to 1A @ 30 VDC
Monitor Inputs
Door Position – N.O. dry contact
Request to Exit – N.O. dry contact
Sounder
4000Hz, defeatable
LEDs
Bi-Color (Red/Green), Amber, Infrared (use with optional palmtop printer)
Operating Temperature
-31º to 150ºF (-35º to 66ºC)
Operating Humidity
5% to 95% relative humidity non-condensing
Cable Distance
Remote Reader Module – 10 feet (3m)
Wiegand Interface – 500 feet (152m)
Recommended cable is ALPHA 1295C (22AWG) 5-conductor stranded with overall shield or equivalent
Operation
Strike Time: 1 – 99 seconds (Adjustable)
Strike Mode: Access Timer or Toggle/Latch
Door Ajar Time: 10 – 990 Seconds (Adjustable)
Card Programming
26-bit format – batch enrollment
OEM proprietary format – present card to enroll
Facility Code Processing Options (26-bit only)
Check Facility Code and Card ID
Check Facility Code only (accept any ID#)
Certifications
UL 294
FCC Certification, United States
Canada Certification
CE Mark, Europe
GS Mark by TÜV Rheinland
Australia C-Tick Mark
New Zealand
Korea
